Product advantages
Technical-parameters
Core advantages
◎ Low Cost、Low power consumption
◎ Better consistency
◎ Better safety
Low Cost、Low power consumption
50~300
Nm³/h
Hydrogen yield
customize
kWh/Nm³
DC power consumption
customize
Year
Power warranty
| Specification |
TP-50 |
TP-100 |
TP-200 |
TP-250 |
TP-300 |
| Rated hydrogen production (Nm³/h) |
50 |
100 |
200 |
250 |
300 |
| Rated oxygen production (Nm³/h) |
25 |
50 |
100 |
125 |
150 |
| Rated electrical density (A/cm2) |
3 |
| Hydrogen pressure (mpa) |
1.5~3.0 |
| Oxygen pressure (mpa) |
0~0.5 |
| Operation temperature (℃ ) |
60±5 |
| Ambient temperature (℃ ) |
5~40 |
| Rated power (kw) |
0.25 |
0.5 |
1 |
1.25 |
1.5 |
| Rated power consumption (kWh/Nm³) |
≤ 4.3 |
| Range (%) |
10~120 |
| Plant Life (h） |
80000 |
| Water quality requirements （µS/cm） |
≤ 0.1 |
